Geniatech XPI-iMX8MM is a credit-card-sized single-board computer that provides an industrial-grade alternative to Raspberry Pi. It is powered by the NXP i.MX8M Mini processor, has 2-4GB RAM, and 8-128GB eMMC storage. The XPI-iMX8MM features stable video encoding and rich expansion interfaces, including Gigabit Ethernet and WiFi/BT functions, four USB ports, and standard 40-pin GPIO headers. It also supports 2 lanes of MIPI LCD and MIPI Camera functions. Suitable for programming education, software education, multimedia terminals, and a wide range of industrial and IoT applications.
XPI-iMX8MM is powered by i.MX8M Mini processor, built using 14LPC FinFET process technology, coupled with 1GB~4GB LPDDR4 RAM and 8GB~128GB eMMC5.1 storage.
XPI-iMX8MM offers high scalability with its support for Gigabit Ethernet and WiFi/BT4.0 functions, four USB ports for USB devices, and 40-pin GPIO headers that can be designated as an input or output pin for various purposes. It also supports 2 lanes of MIPI LCD and MIPI Camera functions.
XPI-iMX8MM supports Yocto (Linux) operating systems, providing a flexible and customizable platform for developers.
Programming education, Software Development, Multimedia terminal
| Processor | Quad core ARM Cortex A53(64bit) Cortex M4 |
| CPU Frequency | 1.8GHz |
| RAM | 1GB LPDDR4(1-4GB Optional) |
| ROM | 8GB eMMC5.1(8-128GB Optional) |
| OS | Linux(Yocto) |
| WLAN | Support USB-WIFI Module, Wi-Fi 5 dual band 2.4GHz/5GHz(optional) Bluetooth 4.1(integration) |
| Ethernet | Gigabit Ethernet |
| Mutlimedia | • 1080p60 MPEG4 Decoder • 1080p60 AVC/H.264 Baseline, Main, High decoder • 1080p60 AVC/H.264 Encoder |
| Display | HDMI®V1.4 Type A |
| USB | USB 2.0 Type A *4, |
| TF-Card | SDIO 3.0 |
| Button | Power/Reset |
| Audio | 4-pole stereo audio and composite video port |
| Indicator light | Power light*1 System status light*1 |
| Connectivity | 1x Standard 40-pin GPIO header • Can be expanded to UART, SPI, I2C ,PWM function 1×4 pin USB-Wifi connector • Support USB-Wifi Module 1x MIPI DSI • 2-lane MIPI DSI display port 1x MIPI cSI • 2-lane MIPI CSI camera port |
| Size (mm) | 85*56 |
| Power | 1GB LPDDR4(1-4GB Optional) |
| Wide working range | Consumer (0°C to 95°C Tj) Industrial (-40°C to 105°C Tj) |
| RoHS and Reach compliant | Yes |
